Key Specifications / Features
This ASTM A351 CF8 Floating Ball Valve is built to API 6D standards for dependable shutoff and flow control. Featuring a cast stainless steel body with an SS 304/SS 316 ball, it delivers excellent corrosion resistance and durability. Sized at 6 inches (DN150) with a pressure rating of Class 150 LB (PN16), the valve includes RF flanged ends for easy installation, making it ideal for general industrial, water, and chemical service applications.
- Model no.: VPSK-20250507-BAV-02
- Hits: 0
- Categories: Ball Valves
- Tags: API 6D Ball Valve , Floating Ball Valve , ASTM A351 CF8 Ball Valve
Detail Information
Product Name: ASTM A351 CF8 Floating Ball Valve
Type: Floating Ball Valve
Design Standard: API 6D
Body Material: ASTM A351 CF8
Ball Material: SS 304/SS 316
Seat Material: RPTFE
Size: DN150, 6 Inch
Pressure Rating: PN16, Class 150 LB
End Connection: RF Flanged
Operation: Bare Shaft
Medium: Water, Oil, Gas, etc
Standards
Design & Manufacturing: ASME B16.34, BS 5351, API 6D
Face to Face: ASME B16.10, API 6D
Test & Inspection: API 598, API 6D
Flange End: ASME B16.5
