Valves play a crucial role as key components in industrial pipeline systems. Their primary function is to regulate or control the flow of fluids, ensuring the smooth operation of the entire system. The sealing performance of valves directly impacts the safety, efficiency, and economy of equipment, especially in high-pressure, high-temperature, and highly corrosive environments. In such conditions, the sealing performance of valves becomes even more critical. Effective sealing ensures that media do not leak, reducing energy wastage and preventing environmental pollution or safety accidents caused by leaks. As a result, research and development of valve sealing technology has long been an important subject in industrial engineering.
The basic task of valve sealing is to prevent leakage of media. Leakage typically occurs due to a combination of factors, including the gap between the sealing elements, the physical properties of the media, the pressure differential between sealing surfaces, and the operating conditions of the valve. The performance of valve sealing is closely linked to the quality of valve design and manufacturing, as well as to factors like working environment, media properties, and operating conditions.
The sealing of liquid media is generally more stable and easier to control compared to gaseous media. The primary mechanism for liquid sealing relies on the pressure difference between the sealing elements' surfaces. These sealing elements, which include the valve seat and the valve plug, come into contact under pressure, preventing liquids from leaking through the gap between them. To improve liquid sealing effectiveness, media with higher viscosity are often chosen. The higher the viscosity of the liquid, the lower its flowability, making it more difficult to permeate the gap between sealing surfaces, thereby improving sealing performance.
The sealing effect of liquid media is also closely related to surface tension. The intermolecular attraction (surface tension) of liquids causes the liquid to avoid penetrating the contact surface of the sealing elements. Thus, rational sealing design can minimize the possibility of leakage by maximizing the surface tension effect.
In contrast to liquids, gas sealing is more challenging. This is because gas molecules are more spread out, and even small gaps between sealing surfaces can lead to leakage. Gas sealing performance depends not only on the pressure differential between sealing surfaces but also on the molecular movement, viscosity, and density of the gas. Since gas molecules are smaller than liquid molecules, they can leak through even microscopic gaps, necessitating stricter sealing requirements.
Moreover, fluctuations in temperature and pressure can affect the sealing performance of gases. High temperatures can soften or expand sealing materials, while low temperatures can cause materials to become brittle or contract. Therefore, when designing gas seals, it is essential to consider both the material's adaptability and the impact of temperature on the material.
Poisson's formula is a fundamental equation that describes the flow of fluids within pipes. When applied to valve sealing, this formula helps analyze the flow behavior of liquids and gases within the gaps between sealing elements. The formula indicates that the permeability of fluid through a capillary is inversely proportional to the capillary diameter and the fluid's viscosity, and directly proportional to the pressure differential and the fluid's density. Therefore, by adjusting the structural parameters of sealing elements (such as gap size) and using fluids with higher viscosity, the sealing performance can be significantly enhanced, reducing leakage.
Valve sealing elements refer to the contact parts between the valve seat and the valve plug, as well as between the valve body and the packing. The design quality of these sealing elements directly determines the sealing performance of the valve. A high-quality sealing element ensures that the media will not leak under different working conditions, maintaining the system's safety and reliability. When designing sealing elements, engineers need to consider various factors such as material selection, structural design, and surface treatment to ensure optimal sealing performance.
The selection of materials for sealing elements is one of the key factors influencing sealing performance. Different operating conditions require different sealing materials. For example, under high-temperature, high-pressure, or corrosive conditions, materials with high resistance to heat and corrosion must be chosen. Common valve sealing materials include metals, rubber, and PTFE (polytetrafluoroethylene). The choice of material must consider not only the physical and chemical properties of the media but also whether the sealing elements will be subject to wear, corrosion, or deformation during operation.
Metal seals are well-suited for high-temperature and high-pressure environments due to their strong resistance to heat and corrosion. Rubber seals, on the other hand, perform excellently in low-temperature and low-pressure environments. PTFE seals, with their excellent chemical resistance, are widely used in valve seals for industries such as chemicals and petroleum.
The design of the sealing surface is crucial for the performance of the sealing element. Valve sealing surfaces need to have certain levels of flatness and smoothness to ensure an effective seal. If the sealing surface is rough or uneven, the sealing effect can be compromised, potentially leading to leakage. To improve the sealing effect, some high-performance valves are coated with hard alloys to enhance the contact force between sealing surfaces.
The compatibility of sealing elements also plays a crucial role in the sealing performance of the valve. When the sealing surface bears the pressure of the media, improper alignment may cause leakage. Therefore, a well-designed sealing element ensures that the sealing surface generates appropriate pressure during valve operation to achieve a strong sealing effect.
In addition to the design of sealing elements, the performance of valve sealing is also influenced by several other factors. These include the physical properties of the working media, changes in the operating temperature, and the duration and frequency of valve operation. Therefore, designers must consider these factors to ensure that the valve can maintain stable sealing performance in various environments.
Temperature fluctuations can have a significant impact on the sealing elements of a valve. High temperatures can cause sealing materials to expand or soften, which may negatively affect sealing performance. Conversely, low temperatures can cause sealing materials to become brittle or shrink, leading to a decline in sealing effectiveness. Therefore, when designing valves, it is necessary to select sealing materials with thermal expansion coefficients that match the temperature variations of the media and consider the thermal compensation function of the sealing elements.
The pressure on the sealing surface directly affects the valve's sealing performance. If the pressure is too high, it may cause plastic deformation of the sealing surface, which could compromise the seal. On the other hand, if the pressure is too low, the sealing surface may fail to form a proper seal, resulting in leakage. Therefore, reasonable pressure design is key to improving sealing performance.
The physical properties of the media, such as its viscosity, surface tension, and corrosiveness, also have a significant impact on valve sealing performance. For high-viscosity fluids, liquid media sealing is relatively easier, whereas low-viscosity gases present more prominent leakage issues. Corrosive media can degrade sealing materials, reducing sealing effectiveness. When designing a valve, it is essential to consider the physical and chemical properties of the media to choose the appropriate sealing materials and structural design.
Valve leakage can be classified into internal and external leakage. Internal leakage refers to the leakage of media through the sealing elements between the valve seat and the valve plug when the valve is closed. External leakage occurs when media leak from the valve body's seams, packing gland, or valve cap.
Internal leakage usually occurs when the seal between the valve seat and valve plug is not properly formed. This can be caused by wear of the sealing surfaces, material aging, or changes in working conditions. To prevent internal leakage, valve designs should ensure that the sealing surfaces are smooth and even, avoiding wear or corrosion that could compromise the seal.
External leakage primarily occurs at the seams between the valve body and valve cap, or at the contact points between the packing gland and valve stem. External leakage not only leads to energy waste but can also result in environmental pollution or safety accidents. To prevent external leakage, it is important to use high-quality packing materials, enhance the sealing design of the packing gland, and take appropriate measures to protect the sealing elements, ensuring that external leakage is minimized.
The sealing performance of a valve directly affects its service life, the safety of the system, and the stability of the production process. In practical applications, sealing design should comprehensively consider various factors such as media properties, operating environment, and temperature variations. The appropriate selection of sealing materials and design schemes is essential to ensuring that the valve operates effectively under different working conditions. With ongoing technological advancements, valve sealing technology continues to evolve. The adoption of advanced materials and design methods will help improve sealing performance, reduce leakage, and enhance the overall performance and efficiency of equipment and production processes.
